Volume pricing
- 1+ pcs$4.85
- 10+ pcs$4.58
- 100+ pcs$4.32
- 500+ pcs$4.08
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Positions Per Level
- 4
- Renk
- Orange
- Özellikler
- Interlocking (Side)
- Genişlik
- 21.6mm
- Yükseklik
- 25.2mm
- Contact Plating
- Tin
- Seri
- Omnimate LM
- Number Of Levels
- 2
- ECCN Kodu
- EAR99
- Montaj Tipi
- Through Hole
- Screw Thread
- M2.5
- Number Of Decks
- 2
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 300V
- Hole Diameter
- 1.3 mm
- Radyasyon Dayanımı
- No
- Wire Gauge Min
- 14 AWG
- Sıra Sayısı
- 2
- RoHS Durumu
- RoHS Compliant
- Onay Kuruluşu
- CSA, cURus
- Safety Approval
- UL; CSA; IEC
- Number Of Ways
- 8
- Orientation
- Straight
- Pitch
- 0.200 5.08mm
- Flammability Rating
- UL94 V-0
- Terminal
- Screw
- Stripping Length
- 6mm
- Ambalaj
- Bulk
- Wire Gauge Max
- 24 AWG
- Wire Gauge
- 14-24 AWG
- Mating Orientation
- Horizontal with Board
- Pozisyon Sayısı
- 8
- Parça Durumu
- Obsolete
- Contact Material Plating
- Copper Alloy - Tin Plated
- Montaj
- Through Hole
- Yayın Yılı
- 2008
- Housing Material
- Thermoplastic, Wemid
- Fabrika Tedarik Süresi
- 11 Weeks
- Kurşunsuz
- Lead Free
