Volume pricing
- 1+ pcs$2.62
- 10+ pcs$2.47
- 100+ pcs$2.33
- 500+ pcs$2.20
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 2
- Wire Gauge Min
- 14 AWG
- Number Of Ways
- 4
- Safety Approval
- UL; CSA; IEC
- Onay Kuruluşu
- CSA, cURus
- Screw Thread
- M2.5
- Montaj Tipi
- Through Hole
- Radyasyon Dayanımı
- No
- Nominal Gerilim
- 300V
- Hole Diameter
- 1.3 mm
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 2
- Seri
- Omnimate LM
- Contact Plating
- Tin
- ECCN Kodu
- EAR99
- Number Of Levels
- 2
- Renk
- Orange
- Genişlik
- 21.6mm
- Özellikler
- Interlocking (Side)
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım
- 15A
- Akım Değeri
- 10A
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -50°C~120°C
- Terminal And Terminal Block Type
- STRIP TERMINAL BLOCK
- Yayın Yılı
- 2009
- Montaj
- Through Hole
- Max Current Rating
- 10A
- Contact Material Plating
- Copper Alloy - Tin Plated
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 12 Weeks
- Housing Material
- Thermoplastic, Wemid
- Number Of Poles
- 4
- Mating Orientation
- Horizontal with Board
- Wire Gauge
- 14-24 AWG
- Depth
- 21.6mm
- Stripping Length
- 6mm
- Terminal
- Solder
