Specifications
- Wire Gauge Or Range Mm
- 1.5-25mm2
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kurşunsuz
- Lead Free
- Uzunluk
- 99mm
- Housing Material
- Nylon
- Fabrika Tedarik Süresi
- 6 Weeks
- Montaj
- DIN Rail
- Yayın Yılı
- 2009
- Parça Durumu
- Active
- Pozisyon Sayısı
- 3
- Material Insulation
- Thermoplastic, Wemid
- Wire Gauge Max
- 14 AWG
- Stripping Length
- 18mm
- Fastening Method
- SPRING LOADED
- Orientation
- Straight
- Additional Feature
- STANDARD: UL 94V-0
- Flammability Rating
- UL94 V-0
- Number Of Ways
- 3
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Terminal Stili
- Push In, Spring
- Safety Approval
- UL; CSA; CE
- Sıra Sayısı
- 1
- Wire Gauge Min
- 4 AWG
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Awg
- 4-14 AWG
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Rated Voltage
- 800V
- ECCN Kodu
- EAR99
- Number Of Levels
- 1
- Housing Color
- Green
- Seri
- Z
- Tip
- Ground, Earth
- Yükseklik
- 50.5mm
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 12.1mm
- Renk
- Green, Yellow
