Volume pricing
- 1+ pcs$6.81
- 10+ pcs$6.42
- 100+ pcs$6.06
- 500+ pcs$5.72
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Orientation
- Straight
- Additional Feature
- STANDARD: UL 94V-0
- Flammability Rating
- UL94 V-0
- Fastening Method
- SPRING LOADED
- Stripping Length
- 18mm
- Currentul
- 60A
- Wire Gauge Max
- 16 AWG
- Voltageiec
- 800V
- Material Insulation
- Thermoplastic, Wemid
- Gerilim
- 600V
- Pozisyon Sayısı
- 3
- Parça Durumu
- Active
- Yayın Yılı
- 2009
- Montaj
- Panel
- Fabrika Tedarik Süresi
- 6 Weeks
- Housing Material
- Nylon
- Uzunluk
- 99mm
- Akım
- 50A
- Kurşunsuz
- Lead Free
- Akım Değeri
- 57A
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Or Range Mm
- 1.5-16mm2
- Renk
- Beige
- Genişlik
- 10.1mm
- Material Flammability Rating
- UL94 V-0
- Yükseklik
- 49.5mm
- Tip
- Feed Through
- Seri
- Z
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Radyasyon Dayanımı
- No
- Nominal Gerilim
- 800V
- Wire Gauge Or Range Awg
- 6-16 AWG
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Min
- 6 AWG
- Sıra Sayısı
- 3
- Safety Approval
- UL; CSA; CE
- Terminal Stili
- Push In, Spring
