Volume pricing
- 1+ pcs$6.83
- 10+ pcs$6.44
- 100+ pcs$6.08
- 500+ pcs$5.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.40
- Pozisyon Sayısı
- 2
- Wire Gauge Or Range Awg
- 4-14 AWG
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 600V
- Stripping Length
- 18mm
- Fabrika Tedarik Süresi
- 6 Weeks
- ECCN Kodu
- EAR99
- Akım Değeri
- 76A
- Terminal Stili
- Push In, Spring
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Currentiec
- 76A
- Wire Gauge Max
- 14 AWG
- Material Insulation
- Thermoplastic, Wemid
- Flammability Rating
- UL94 V-0
- Tip
- Feed Through
- Akım
- 65A
- Yayın Yılı
- 2012
- Seri
- Z
- Additional Feature
- 94V-0
- Wire Gauge Or Range Mm
- 1.5-16mm2
- Yükseklik
- 50.5mm
- Number Of Levels
- 1
- Sıra Sayısı
- 1
- Uzunluk
- 82.5mm
- Fastening Method
- SCREW
- Safety Approval
- UL; CSA
- Terminal Width
- 15.0mm
- Wire Gauge Min
- 4 AWG
- Number Of Decks
- 1
- Renk
- Blue
- Nominal Gerilim
- 500V
- Gerilim
- 500V
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Genişlik
- 15mm
