Volume pricing
- 1+ pcs$6.87
- 10+ pcs$6.48
- 100+ pcs$6.11
- 500+ pcs$5.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Stili
- Push In, Spring
- Wire Gauge Max
- 26 AWG
- Max Supply Voltage
- 400V
- Akım Değeri
- 6.3A
- Tip
- Disconnect, Isolated
- Flammability Rating
- UL94 V-0
- Material Insulation
- Thermoplastic, Wemid
- Wire Gauge Or Range Awg
- 12-26 AWG
- Kurşunsuz
- Lead Free
- Onay Kuruluşu
- CE, IEC
- Number Of Ways
- 5
- Housing Material
- Nylon
- Pozisyon Sayısı
- 5
- Fabrika Tedarik Süresi
- 8 Weeks
- ECCN Kodu
- EAR99
- Number Of Circuits
- 2
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 10mm
- Voltageiec
- 400V
- Nominal Gerilim
- 6kV
- Renk
- Beige
- Material Flammability Rating
- UL94 V-0
- Number Of Decks
- 2
- Wire Gauge Min
- 12 AWG
- Genişlik
- 5.1mm
- Fuse Type
- 5mm x 20mm
- Parça Durumu
- Active
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Seri
- Z
- Yayın Yılı
- 2008
- Disconnect Type
- Fuse, Removable Plug
- Safety Approval
- CE
- Fastening Method
- SPRING LOADED
- Uzunluk
- 95mm
- Radyasyon Dayanımı
- No
- Number Of Levels
- 3; 1 Grounded
- Yükseklik
- 98mm
- Orientation
- Straight
- Sıra Sayısı
- 4
