Specifications
- Çalışma Sıcaklığı
- -50°C~100°C
- Montaj
- Free Hanging, Panel
- Din Conformance
- NO
- Kurşunsuz Kodu
- yes
- Montaj Tipi
- Free Hanging (In-Line)
- Housing Material
- Polybutylene Terephthalate (PBT)
- Depth
- 20.6mm
- Özellikler
- Mating Flange
- Flammability Rating
- UL94 V-0
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 250V
- Wire Gauge Or Range Awg
- 16-28 AWG
- Tip
- Plug, Female Sockets
- Uzunluk
- 52.5mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Max Supply Voltage
- 150V
- Gerilim
- 150V
- Kurşunsuz
- Lead Free
- Genişlik
- 15.6mm
- Orientation
- Straight
- Option
- GENERAL PURPOSE
- Terminal Stili
- Screwless - Spring Cage, Tension Clamp
- Seri
- Omnimate B2L
- Pozisyon Sayısı
- 26
- Positions Per Level
- 13
- Wire Gauge Min
- 18 AWG
- Iec Conformance
- NO
- Number Of Levels
- 2
- Contact Materials
- Copper Alloy
- RoHS Durumu
- RoHS Compliant
- Akım
- 10A
- Wire Gauge Max
- 28 AWG
- Mixed Contacts
- NO
- Max Current Rating
- 10A
- Sıra Sayısı
- 2
- Currentiec
- 10.3A
- Radyasyon Dayanımı
- No
- Wire Gauge Or Range Mm
- 0.2-1mm2
- Pitch
- 0.138 3.50mm
- Total Number Of Contacts
- 26
