Specifications
- Plug Wire Entry
- 180°
- Ingress Protection
- IP20
- Contact Mating Finish
- Tin
- Terminal
- Crimp
- Number Of Positions Per Level
- 13
- Mil Conformance
- NO
- Filter Feature
- NO
- Insulation Height
- 0.618 15.70mm
- Renk
- Orange
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Insulation Resistance
- 1MOhm
- Yayın Yılı
- 2002
- Wire Strip Length
- 7mm
- Total Number Of Contacts
- 26
- Pitch
- 0.138 3.50mm
- Wire Gauge Or Range Mm
- 0.2-1mm2
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 2
- Currentiec
- 10.3A
- Max Current Rating
- 10A
- Mixed Contacts
- NO
- Wire Gauge Max
- 22 AWG
- Akım
- 10A
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- Copper Alloy
- Number Of Levels
- 2
- Iec Conformance
- NO
- Wire Gauge Min
- 16 AWG
- Pozisyon Sayısı
- 26
- Seri
- Omnimate B2L
- Terminal Stili
- Screwless - Spring Cage, Tension Clamp
- Option
- GENERAL PURPOSE
- Orientation
- Straight
- Genişlik
- 20.6mm
- Kurşunsuz
- Lead Free
- Gerilim
- 150V
- Max Supply Voltage
- 150V
- Fabrika Tedarik Süresi
- 12 Weeks
- Uzunluk
- 45.5mm
