Volume pricing
- 1+ pcs$9.05
- 10+ pcs$8.54
- 100+ pcs$8.06
- 500+ pcs$7.60
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Color
- Green
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Genişlik
- 10.1mm
- Terminal
- Screw
- Safety Approval
- ATEX; CE; CSA; CURUSEX; DNV
- Wire Gauge Max
- 16 AWG
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Radyasyon Dayanımı
- No
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2008
- Tip
- Ground, Earth
- Parça Durumu
- Active
- Min. Çalışma Sıcaklığı
- -50°C
- Terminal Stili
- Push In, Spring
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- Not Applicable
- Housing Material
- Nylon
- Yükseklik
- 49.5mm
- Wire Gauge Min
- 6 AWG
- Material Insulation
- Thermoplastic, Wemid
- Maks. Çalışma Sıcaklığı
- 100°C
- Uzunluk
- 73.5mm
- Wirecable Gauge
- 6 AWG
- Number Of Ways
- 2
- Sıra Sayısı
- 1
- Nominal Gerilim
- 800V
- Renk
- Green, Yellow
- HTS Kodu
- 8536.69.40.40
- Number Of Contacts
- 2
- Stripping Length
- 18mm
- Number Of Levels
- 1
- Number Of Decks
- 1
- Additional Feature
- STANDARD: 94V-0; GOSTEX; IEC EX; KEMA ; PCT; UL
- Seri
- Z
- Wire Gauge Or Range Mm
- 1.5-16mm2
- Wire Gauge Or Range Awg
- 6-16 AWG
- Fabrika Tedarik Süresi
- 6 Weeks
