Specifications
- Flammability Rating
- UL94 V-0
- Radyasyon Dayanımı
- No
- Yayın Yılı
- 2009
- Parça Durumu
- Active
- Tip
- Feed Through
- Terminal Width
- 10.0mm
- Terminal Stili
- Push In, Spring
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- Akım Değeri
- 40A
- Housing Color
- Green
- Fastening Method
- SCREW
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Genişlik
- 10mm
- Safety Approval
- UL; CSA; CE
- Wire Gauge Max
- 16 AWG
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Material Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Additional Feature
- STANDARD: UL 94V-0
- Seri
- Z
- Wire Gauge Or Range Mm
- 1.5-16mm2
- Voltageiec
- 400V
- Wire Gauge Or Range Awg
- 6-16 AWG
- Fabrika Tedarik Süresi
- 8 Weeks
- Yükseklik
- 48mm
- Wire Gauge Min
- 6 AWG
- Material Insulation
- Thermoplastic, Wemid
- Uzunluk
- 86.5mm
- Wirecable Gauge
- 6 AWG
- Sıra Sayısı
- 1
- Nominal Gerilim
- 6kV
- Renk
- Green, Yellow
- HTS Kodu
- 8536.69.40.40
- Stripping Length
- 18mm
- Number Of Contacts
- 2
- Number Of Levels
- 1
