Specifications
- Stripping Length
- 18mm
- Number Of Contacts
- 2
- Number Of Levels
- 1
- HTS Kodu
- 8536.69.40.40
- Renk
- Blue
- Nominal Gerilim
- 400V
- Uzunluk
- 86.5mm
- Material Insulation
- Thermoplastic, Wemid
- Sıra Sayısı
- 1
- Wire Gauge Min
- 6 AWG
- Yükseklik
- 48mm
- Voltageiec
- 400V
- Fabrika Tedarik Süresi
- 8 Weeks
- Wire Gauge Or Range Awg
- 6-16 AWG
- Seri
- Z
- Additional Feature
- STANDARD: UL 94V-0
- Wire Gauge Or Range Mm
- 1.5-16mm2
- Currentiec
- 57A
- Number Of Decks
- 1
- Wire Gauge Max
- 16 AWG
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Material Flammability Rating
- UL94 V-0
- Safety Approval
- UL; CSA; CE
- Onay Kuruluşu
- CE, CSA, IEC, cURus
- Fastening Method
- SCREW
- Genişlik
- 10mm
- Akım
- 60A
- Akım Değeri
- 57A
- Orientation
- Straight
- Gerilim
- 600V
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2009
- Flammability Rating
- UL94 V-0
- Radyasyon Dayanımı
- No
- Terminal Stili
- Push In, Spring
- Terminal Width
- 10.0mm
- Parça Durumu
- Active
- Tip
- Feed Through
