Volume pricing
- 1+ pcs$14.34
- 10+ pcs$13.53
- 100+ pcs$12.76
- 500+ pcs$12.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 6 Weeks
- Renk
- Green, Yellow
- Terminal Stili
- Screw
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Additional Feature
- STANDARD: UL 94V-0
- ECCN Kodu
- EAR99
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 400V
- Uzunluk
- 66mm
- Akım Değeri
- 20A
- Yükseklik
- 50.5mm
- Tip
- Ground, Earth
- Material Insulation
- Thermoplastic, Wemid
- Seri
- W
- Sıra Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Min
- 2 AWG
- Terminal Width
- 16.0mm
- Wirecable Gauge
- 2 AWG
- Number Of Levels
- 1
- Onay Kuruluşu
- CE, IEC
- Radyasyon Dayanımı
- No
- Housing Color
- Green
- Stripping Length
- 18mm
- Safety Approval
- CE
- Wire Gauge Max
- 12 AWG
- Wire Gauge Or Range Awg
- 2-12 AWG
- Genişlik
- 16mm
- Parça Durumu
- Active
- Yayın Yılı
- 2012
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Wire Gauge Or Range Mm
- 2.5-50mm2
