Specifications
- Uzunluk
- 20.32mm
- Çalışma Sıcaklığı
- -50°C~100°C
- Filter Feature
- NO
- Wire Gauge Or Range Awg
- 14-26 AWG
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 14 Weeks
- Plug Wire Entry
- 180°
- Contact Mating Finish
- Tin
- Housing Material
- Polyamide (PA), Nylon
- Genişlik
- 17.4mm
- JESD-609 Kodu
- e3
- Pitch
- 0.200 5.08mm
- Contact Materials
- Copper Alloy
- Max Current Rating
- 15A
- Wire Strip Length
- 6mm
- Flammability Rating
- UL94 V-2
- Din Conformance
- NO
- Akım
- 10A
- Montaj Tipi
- Free Hanging (In-Line)
- Screw Size
- M2.5
- Material Flammability Rating
- UL94 V-0
- Özellikler
- Retention Latches (Non-Wire Side)
- Iec Conformance
- NO
- Seri
- Omnimate BL
- Kurşunsuz Kodu
- yes
- Terminal Stili
- Screw - Leaf Spring, Wire Guard
- Sıra Sayısı
- 1
- Option
- GENERAL PURPOSE
- Wire Gauge Min
- 14 AWG
- Pozisyon Sayısı
- 4
- Terminal
- Screw
- Nem Hassasiyeti (MSL)
- Not Applicable
- Mixed Contacts
- NO
- Number Of Contacts
- 4
- Wire Gauge Max
- 26 AWG
- Renk
- Orange
- Kurşunsuz
- Lead Free
- Montaj
- Cable, Free Hanging
- Number Of Levels
- 1
- Voltageiec
- 400V
