Specifications
- Contact Mating Finish
- Tin
- Plug Wire Entry
- 180°
- Fabrika Tedarik Süresi
- 6 Weeks
- Housing Material
- Polyamide (PA), Nylon
- Uzunluk
- 15.24mm
- Parça Durumu
- Active
- Wire Gauge Or Range Awg
- 14-26 AWG
- Filter Feature
- NO
- Çalışma Sıcaklığı
- -50°C~100°C
- Material Flammability Rating
- UL94 V-0
- Screw Size
- M2.5
- Montaj Tipi
- Free Hanging (In-Line)
- Iec Conformance
- NO
- Ul Flammability Code
- 94V-2
- Reach Svhc
- No SVHC
- Özellikler
- Retention Latches (Non-Wire Side)
- Max Current Rating
- 15A
- Contact Materials
- Copper Alloy
- Pitch
- 0.200 5.08mm
- JESD-609 Kodu
- e3
- Genişlik
- 17.4mm
- Akım
- 10A
- Din Conformance
- NO
- Flammability Rating
- UL94 V-2
- Voltage Rated Ac
- 380V
- Wire Strip Length
- 6mm
- Mixed Contacts
- NO
- Voltageiec
- 400V
- Montaj
- Cable, Free Hanging
- Number Of Levels
- 1
- Kurşunsuz
- Lead Free
- Renk
- Orange
- Wire Gauge Max
- 26 AWG
- Number Of Contacts
- 3
- Wire Gauge Min
- 14 AWG
- Option
- GENERAL PURPOSE
- Sıra Sayısı
- 1
- Wirecable Gauge
- 22 AWG
- Terminal Stili
- Screw - Leaf Spring, Wire Guard
- Kurşunsuz Kodu
- yes
