Volume pricing
- 1+ pcs$14.29
- 10+ pcs$13.48
- 100+ pcs$12.72
- 500+ pcs$12.00
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz
- Lead Free
- Number Of Ways
- 24
- Number Of Levels
- 2
- Wire Gauge Min
- 14 AWG
- Number Of Decks
- 2
- Renk
- Orange
- Hole Diameter
- 1.3 mm
- Onay Kuruluşu
- CSA, UR
- Flammability Rating
- UL94 V-2
- Seri
- Omnimate LM
- Akım Değeri
- 10A
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Terminal
- Solder
- Uzunluk
- 42.6mm
- Wire Gauge
- 14-28 AWG
- Genişlik
- 16.8mm
- Çalışma Sıcaklığı
- -50°C~100°C
- Ambalaj
- Bulk
- Sıra Sayısı
- 2
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Max
- 28 AWG
- Depth
- 16.75mm
- Mating Orientation
- Horizontal with Board
- Safety Approval
- UL; VDE; CSA
- Contact Plating
- Tin
- HTS Kodu
- 8536.69.40.40
- Contact Material Plating
- Copper Alloy - Tin Plated
- Montaj
- Through Hole
- Parça Durumu
- Obsolete
- Kurşunsuz Kodu
- yes
- Radyasyon Dayanımı
- No
- Nominal Gerilim
- 300V
- Yayın Yılı
- 2008
- Positions Per Level
- 12
- Insulation Materials
- Nylon
- Orientation
- Straight
- Stripping Length
- 5mm
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Fabrika Tedarik Süresi
- 13 Weeks
