Volume pricing
- 1+ pcs$8.98
- 10+ pcs$8.47
- 100+ pcs$7.99
- 500+ pcs$7.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Levels
- 1
- Ul Flammability Code
- 94V-0
- Plug Wire Entry
- 180°
- Wire Gauge Min
- 14 AWG
- Gerilim
- 300V
- Montaj Tipi
- Free Hanging (In-Line)
- Connector Type
- Terminal Block
- Uzunluk
- 28mm
- Wire Gauge Max
- 26 AWG
- Filter Feature
- NO
- Parça Durumu
- Active
- Wire Gauge Or Range Awg
- 14-26 AWG
- Number Of Contacts
- 8
- Housing Material
- Polybutylene Terephthalate (PBT)
- Flammability Rating
- UL94 V-0
- Material Flammability Rating
- UL94 V-0
- Wirecable Gauge
- 26 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- HIGH DENSITY
- Terminal
- Screwless
- Currentiec
- 14.5A
- JESD-609 Kodu
- e3
- Akım
- 10A
- Contact Materials
- Copper Alloy
- Pitch
- 0.138 3.50mm
- Terminal Stili
- Screwless - Spring Cage, Tension Clamp
- Nominal Gerilim
- 300V
- Yükseklik
- 13mm
- Çalışma Sıcaklığı
- -50°C~100°C
- Akım Değeri
- 14.5A
- Insulation Height
- 0.512 13.00mm
- Genişlik
- 21.9mm
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 1
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Option
- GENERAL PURPOSE
- Onay Kuruluşu
- CSA, UR
- Ambalaj
- Bulk
- Orientation
- Straight
