Volume pricing
- 1+ pcs$11.11
- 10+ pcs$10.48
- 100+ pcs$9.89
- 500+ pcs$9.33
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 6 Weeks
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Awg
- 12-26 AWG
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 20A
- Housing Material
- Nylon
- Seri
- Z
- Akım
- 20A
- Wire Gauge Or Range Mm
- 0.5-2.5mm2
- Genişlik
- 5.1mm
- Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 500V
- Pozisyon Sayısı
- 4
- Wire Gauge Max
- 26 AWG
- ECCN Kodu
- EAR99
- Sıra Sayısı
- 2
- Number Of Decks
- 2
- Orientation
- Straight
- Wire Gauge Min
- 12 AWG
- Number Of Ways
- 4
- Parça Durumu
- Active
- Fastening Method
- SPRING LOADED
- Terminal Stili
- Push In, Spring
- Stripping Length
- 10mm
- Renk
- Beige
- Nem Hassasiyeti (MSL)
- Not Applicable
- Radyasyon Dayanımı
- No
- Number Of Levels
- 2; Connected
- Wirecable Gauge
- 12 AWG
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 500V
- RoHS Durumu
- RoHS Compliant
- Currentul
- 15A
- Yükseklik
- 53mm
- Safety Approval
- ATEX; CE; CSA; DNV; KEMA; GOST
- Onay Kuruluşu
- CE, CSA, IEC
- Material Insulation
- Thermoplastic, Wemid
- Tip
- Feed Through
- Yayın Yılı
- 2009
- Gerilim
- 300V
