Volume pricing
- 1+ pcs$2.56
- 10+ pcs$2.42
- 100+ pcs$2.28
- 500+ pcs$2.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 64.5mm
- Kurşunsuz
- Lead Free
- Wire Gauge Max
- 30 AWG
- Terminal Stili
- Push In, Spring
- Material Flammability Rating
- UL94 V-0
- Voltageiec
- 800V
- Genişlik
- 5.1mm
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Wire Gauge Min
- 12 AWG
- Renk
- Green
- Material Insulation
- Thermoplastic, Wemid
- Safety Approval
- UL; CSA; CE
- Stripping Length
- 10mm
- Tip
- Feed Through
- Nem Hassasiyeti (MSL)
- Not Applicable
- Gerilim
- 600V
- Yayın Yılı
- 2009
- Wire Gauge Or Range Awg
- 12-30 AWG
- Number Of Decks
- 1
- Fastening Method
- SPRING LOADED
- Radyasyon Dayanımı
- No
- Akım Değeri
- 24A
- Nominal Gerilim
- 8kV
- Sıra Sayısı
- 2
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- STANDARD: UL 94V-0
- Parça Durumu
- Active
- Seri
- Z
- Orientation
- Straight
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Flammability Rating
- UL94 V-0
- Housing Material
- Nylon
- Number Of Levels
- 1
- Currentul
- 25A
- Akım
- 21A
- Yükseklik
- 38.5mm
- Pozisyon Sayısı
- 3
- Fabrika Tedarik Süresi
- 8 Weeks
