Volume pricing
- 1+ pcs$3.11
- 10+ pcs$2.93
- 100+ pcs$2.77
- 500+ pcs$2.61
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Plating
- Tin
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Renk
- Orange
- Depth
- 8.3mm
- Sıra Sayısı
- 1
- Mating Orientation
- Horizontal with Board
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yayın Yılı
- 2008
- Contact Material Plating
- Copper Alloy - Tin Plated
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Screw Thread
- M2
- Stripping Length
- 5mm
- Özellikler
- Interlocking (Side)
- Ambalaj
- Bulk
- ECCN Kodu
- EAR99
- Montaj Tipi
- Through Hole
- Genişlik
- 8.3mm
- Onay Kuruluşu
- CSA, UR
- Hole Diameter
- 1.3 mm
- Akım Değeri
- 10A
- Wire Gauge
- 14-28 AWG
- Number Of Decks
- 1
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Fabrika Tedarik Süresi
- 16 Weeks
- Number Of Levels
- 1
- Housing Material
- Polyamide (PA), Nylon
- Pozisyon Sayısı
- 3
- Uzunluk
- 11.1mm
- Additional Feature
- PA, 94V-2
- Terminal
- Solder
- Safety Approval
- UL; VDE; CSA
- Nominal Gerilim
- 300V
- Seri
- Omnimate LM
- Max Current Rating
- 12A
- Max Supply Voltage
- 300V
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Min
- 14 AWG
- Montaj
- Through Hole
- Insulation Materials
- Nylon
