Specifications
- Wire Gauge
- 6-26 AWG
- Ambalaj
- Bulk
- Wire Gauge Min
- 6 AWG
- Uzunluk
- 31.08mm
- Housing Color
- Grey
- ECCN Kodu
- EAR99
- Terminal And Terminal Block Type
- STRIP TERMINAL BLOCK
- Mating Orientation
- Horizontal with Board
- Pitch
- 0.400 10.16mm
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Number Of Levels
- 1
- Additional Feature
- 94V-0, PA
- Seri
- LU
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2009
- Depth
- 18.3mm
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 12 Weeks
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- Not Applicable
- Radyasyon Dayanımı
- No
- Renk
- Gray
- Onay Kuruluşu
- CSA, UR
- Stripping Length
- 12mm
- Number Of Ways
- 3
- Housing Material
- Polyamide (PA), Nylon
- Terminal
- Solder
- Screw Thread
- M4
- Hole Diameter
- 1.6 mm
- Nominal Gerilim
- 300V
- Montaj Tipi
- Through Hole
- Max Current Rating
- 65A
- Wire Gauge Max
- 26 AWG
- Number Of Decks
- 1
- Contact Material Plating
- Electrolytic Copper - Tin Plated
- Özellikler
- Interlocking (Side)
- Contact Plating
- Tin
- Genişlik
- 18.3mm
- Max Supply Voltage
- 300V
- Kurşunsuz
- Lead Free
