Volume pricing
- 1+ pcs$6.10
- 10+ pcs$5.75
- 100+ pcs$5.43
- 500+ pcs$5.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Reach Svhc
- Unknown
- Number Of Ways
- 2
- Number Of Decks
- 1
- Material Flammability Rating
- UL94 V-0
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Awg
- 10-26 AWG
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Or Range Mm
- 0.5-6mm2
- Parça Durumu
- Active
- Housing Color
- Green
- Nominal Gerilim
- 800V
- Kurşunsuz
- Lead Free
- Fastening Method
- SPRING LOADED
- Nem Hassasiyeti (MSL)
- Not Applicable
- Safety Approval
- ATEX; CE; CSA; CURUSEX; DNV
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Terminal Stili
- Push In, Spring
- Number Of Levels
- 1
- Material Insulation
- Thermoplastic, Wemid
- HTS Kodu
- 8536.69.40.40
- Connector Type
- Terminal Block
- Fabrika Tedarik Süresi
- 8 Weeks
- Sıra Sayısı
- 2
- Wirecable Gauge
- 10 AWG
- Tip
- Ground, Earth
- Genişlik
- 6.1mm
- Yükseklik
- 43mm
- Wire Gauge Max
- 26 AWG
- Uzunluk
- 64mm
- Radyasyon Dayanımı
- No
- Additional Feature
- STANDARD: 94V-0 APROVAL IEC EX; KEMA; PCT; UL
- Maks. Çalışma Sıcaklığı
- 120°C
- Min. Çalışma Sıcaklığı
- -50°C
- Renk
- Green, Yellow
- Wire Gauge Min
- 10 AWG
- Housing Material
- Nylon
- Seri
- Z
- Yayın Yılı
- 2005
