Volume pricing
- 1+ pcs$9.53
- 10+ pcs$8.99
- 100+ pcs$8.48
- 500+ pcs$8.00
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 22.2mm
- Insulation Resistance
- 1MOhm
- Seri
- Omnimate SL
- Contact Mating Finish
- Tin
- Max Supply Voltage
- 300V
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Currentul
- 14A
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -50°C~100°C
- Din Conformance
- NO
- Akım
- 10A
- Insulation Height
- 0.598 15.19mm
- Nominal Gerilim
- 300V
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Tip
- Plug, Male Pins
- Kurşunsuz
- Lead Free
- Genişlik
- 22.3mm
- Pitch
- 0.200 5.08mm
- Flammability Rating
- UL94 V-0
- Total Number Of Contacts
- 7
- JESD-609 Kodu
- e3
- Stripping Length
- 7mm
- Iec Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- Filter Feature
- NO
- Plug Wire Entry
- 180°
- Contact Materials
- Copper Alloy
- Ul Flammability Code
- 94V-0
- Renk
- Orange
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Mil Conformance
- NO
- Mixed Contacts
- NO
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-26 AWG
- Terminal
- Screw
- Gerilim
- 300V
- Fabrika Tedarik Süresi
- 12 Weeks
- Orientation
- Right Angle
- Number Of Positions Per Level
- 7
