Specifications
- Contact Mating Finish
- Tin
- Hole Diameter
- 1.3 mm
- Insulation Resistance
- 1MOhm
- Seri
- Omnimate SL
- Insulation Height
- 0.335 8.51mm
- Nominal Gerilim
- 300V
- Din Conformance
- NO
- Akım
- 10A
- Number Of Poles
- 2
- Currentul
- 15A
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -50°C~100°C
- Kurşunsuz Kodu
- yes
- Sıra Sayısı
- 1
- Flammability Rating
- UL94 V-0
- Yükseklik
- 8.5mm
- JESD-609 Kodu
- e3
- Total Number Of Contacts
- 2
- Genişlik
- 12mm
- Pitch
- 0.300 7.62mm
- Kurşunsuz
- Lead Free
- Header Orientation
- 90°, Right Angle
- Tip
- Header, Male Pins, Shrouded (2 Side)
- Filter Feature
- NO
- RoHS Durumu
- RoHS Compliant
- Contact Tail Length
- 0.126 3.20mm
- Iec Conformance
- NO
- Ul Flammability Code
- 94V-0
- Renk
- Orange
- Terminal Stili
- Solder
- Contact Materials
- Copper Alloy
- Number Of Levels
- 1
- Uzunluk
- 15.2mm
- Gerilim
- 300V
- Fabrika Tedarik Süresi
- 12 Weeks
- Mil Conformance
- NO
- Mixed Contacts
- NO
- Material Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2008
- Montaj
- Through Hole
