Volume pricing
- 1+ pcs$24.07
- 10+ pcs$22.71
- 100+ pcs$21.42
- 500+ pcs$20.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Maks. Çalışma Sıcaklığı
- 120°C
- Terminal
- Screw
- Weight
- 19.63g
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım Değeri
- 6.3A
- Safety Approval
- CE; CSA; DNV ; GOST; KEMA; UL
- Yayın Yılı
- 2009
- Number Of Ways
- 2
- Parça Durumu
- Active
- Renk
- Beige
- Fuse Type
- 5mm x 20mm
- Wire Gauge Max
- 26 AWG
- Max Current Rating
- 6.3A
- Min. Çalışma Sıcaklığı
- -50°C
- Stripping Length
- 10mm
- Additional Feature
- UL94V-0
- Radyasyon Dayanımı
- No
- Sıra Sayısı
- 2
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Akım
- 6.3A
- Number Of Decks
- 1
- Number Of Levels
- 1
- RoHS Durumu
- RoHS Compliant
- Material Insulation
- Thermoplastic, Wemid
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Fastening Method
- SPRING LOADED
- Terminal Stili
- Push In, Spring
- Seri
- Z
- Wire Gauge Min
- 12 AWG
- Voltageiec
- 500V
- Material Flammability Rating
- UL94 V-0
- Flammability Rating
- UL94 V-0
- Disconnect Type
- Fuse, Removable Plug
- Fabrika Tedarik Süresi
- 8 Weeks
- Max Supply Voltage
- 36V
- Uzunluk
- 79.5mm
- Wire Gauge Or Range Awg
- 12-26 AWG
- Tip
- Disconnect
- Yükseklik
- 73mm
- HTS Kodu
- 8536.69.40.40
