Volume pricing
- 1+ pcs$0.48
- 10+ pcs$0.46
- 100+ pcs$0.43
- 500+ pcs$0.41
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Number Of Ways
- 3
- Kurşunsuz Kodu
- yes
- Stripping Length
- 10mm
- Akım
- 21A
- Uzunluk
- 64.5mm
- Maks. Çalışma Sıcaklığı
- 120°C
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Awg
- 12-30 AWG
- Wire Gauge Max
- 30 AWG
- Renk
- Beige
- Number Of Levels
- 1
- Akım Değeri
- 24A
- Material Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Fastening Method
- SPRING LOADED
- Tip
- Feed Through
- Reach Svhc
- No SVHC
- Depth
- 5.1mm
- Max Current Rating
- 25A
- Wire Gauge Min
- 12 AWG
- Min. Çalışma Sıcaklığı
- -50°C
- Material Insulation
- Thermoplastic, Wemid
- Orientation
- Straight
- Voltageiec
- 800V
- Safety Approval
- UL; CSA; CE
- Montaj
- Through Hole
- Terminal Stili
- Push In, Spring
- Max Supply Voltage
- 600V
- Sıra Sayısı
- 4
- Seri
- Z
- Nominal Gerilim
- 8kV
- Housing Material
- Nylon
- Yayın Yılı
- 2005
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 3
- Gerilim
- 600V
- Genişlik
- 5.1mm
- Flammability Rating
- UL94 V-0
