Volume pricing
- 1+ pcs$0.28
- 10+ pcs$0.27
- 100+ pcs$0.25
- 500+ pcs$0.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Min
- 12 AWG
- Min. Çalışma Sıcaklığı
- -50°C
- Max Current Rating
- 25A
- Voltageiec
- 800V
- Connector Type
- Terminal Block
- Orientation
- Straight
- Material Insulation
- Thermoplastic, Wemid
- Seri
- Z
- Nominal Gerilim
- 8kV
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2001
- Housing Material
- Nylon
- Montaj
- Cable
- Safety Approval
- ATEX; CE; CSA; CURUSEX; DNV
- Sıra Sayısı
- 1
- Terminal Stili
- Push In, Spring
- Additional Feature
- STANDARD: 94V-0 APROVAL IEC; EX KEMA; PCT; UL
- Onay Kuruluşu
- CE, CSA, IEC, UR
- Wirecable Gauge
- 12 AWG
- Genişlik
- 5.1mm
- Gerilim
- 600V
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 10 Weeks
- Yükseklik
- 38.5mm
- Wire Gauge Or Range Mm
- 0.5-4mm2
- Radyasyon Dayanımı
- No
- Currentul
- 25A
- Stripping Length
- 10mm
- Number Of Ways
- 2
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8536.69.40.40
- Uzunluk
- 59.5mm
- Akım
- 21A
- Maks. Çalışma Sıcaklığı
- 120°C
- Number Of Levels
- 1
- Renk
- Beige
- Wire Gauge Or Range Awg
- 12-30 AWG
- Kurşunsuz
- Lead Free
