Volume pricing
- 1+ pcs$4.64
- 10+ pcs$4.37
- 100+ pcs$4.13
- 500+ pcs$3.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Mating Flange
- Terminal
- Screw
- Ambalaj
- Bulk
- Additional Feature
- HIGH DENSITY
- Parça Durumu
- Active
- Connector Type
- Terminal Block
- Total Number Of Contacts
- 16
- Mil Conformance
- NO
- Akım Değeri
- 17A
- Nem Hassasiyeti (MSL)
- Not Applicable
- Renk
- Orange
- Housing Material
- Polybutylene Terephthalate (PBT)
- Yayın Yılı
- 2009
- Max Supply Voltage
- 300V
- Sıra Sayısı
- 1
- Pitch
- 0.138 3.50mm
- Material
- PBT
- Wirecable Gauge
- 28 AWG
- Screw Size
- M2
- Montaj Tipi
- Free Hanging (In-Line)
- Contact Mating Finish
- Tin
- Genişlik
- 18.5mm
- Kurşunsuz Kodu
- yes
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Seri
- Omnimate BL
- Filter Feature
- NO
- Wire Gauge Or Range Awg
- 14-28 AWG
- Akım
- 10A
- Wire Gauge Or Range Mm
- 0.2-1.5mm2
- Plug Wire Entry
- 180°
- Number Of Positions Per Level
- 16
- Çalışma Sıcaklığı
- -50°C~100°C
- Montaj
- Cable, Free Hanging
- RoHS Durumu
- RoHS Compliant
- Number Of Levels
- 1
- Wire Gauge Min
- 14 AWG
- Orientation
- Right Angle
- Max Current Rating
- 10A
- Insulation Height
- 0.512 13.00mm
- Radyasyon Dayanımı
- No
