Volume pricing
- 1+ pcs$6.66
- 10+ pcs$6.29
- 100+ pcs$5.93
- 500+ pcs$5.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- Omnimate SLDF
- Front Panel Wire Connection
- Header, Male Pins
- Contact Materials
- CuSn
- Yayın Yılı
- 2008
- Uzunluk
- 50.14mm
- Additional Feature
- STANDARD: UL 94V-0
- Pitch
- 0.200 5.08mm
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Özellikler
- Lock Opening
- Sıra Sayısı
- 1
- Montaj
- Panel
- Contact Plating
- Tin
- Fabrika Tedarik Süresi
- 12 Weeks
- Number Of Decks
- 1
- Genişlik
- 1.974 50.14mm
- Akım Değeri
- 15A
- Number Of Ways
- 6
- Maks. Çalışma Sıcaklığı
- 100°C
- Rear Panel Wire Connection
- Quick Connect - 0.110 (2.80mm), Solder Eyelet
- Gerilim
- 300V
- Terminal
- Solder
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Kurşunsuz Kodu
- yes
- Number Of Poles
- 6
- ECCN Kodu
- EAR99
- Min. Çalışma Sıcaklığı
- -25°C
- Radyasyon Dayanımı
- No
- Max Current Rating
- 15A
- Wire Cross Section
- 2.5 mm2
- Flammability Rating
- UL94 V-0
- Housing Material
- Polybutylene
- Akım
- 15A
- Fastening Method
- PLUG IN
- Parça Durumu
- Active
- Nominal Gerilim
- 300V
- Orientation
- Straight
- Depth
- 28mm
- Renk
- Orange
- Onay Kuruluşu
- CSA, UR
