Specifications
- Housing Material
- Polybutylene Terephthalate (PBT)
- Yayın Yılı
- 2008
- Mil Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- Number Of Poles
- 2
- Seri
- Omnimate SL
- Nominal Gerilim
- 300V
- Terminal Stili
- Solder
- Sıra Sayısı
- 1
- Montaj
- Through Hole
- Voltageiec
- 320V
- Orientation
- Right Angle
- Header Orientation
- 90°, Right Angle
- Çalışma Sıcaklığı
- -50°C~100°C
- Max Current Rating
- 10A
- Depth
- 11.1mm
- Contact Materials
- Copper Alloy
- Fabrika Tedarik Süresi
- 12 Weeks
- Hole Diameter
- 1.3 mm
- Radyasyon Dayanımı
- No
- Din Conformance
- NO
- Onay Kuruluşu
- CSA, UR
- Flammability Rating
- UL94 V-0
- Insulation Resistance
- 1MOhm
- Gerilim
- 300V
- Genişlik
- 11.1mm
- Akım
- 10A
- Uzunluk
- 7mm
- Iec Conformance
- NO
- Ingress Protection
- IP10
- Mixed Contacts
- NO
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Total Number Of Contacts
- 2
- Contact Tail Length
- 0.126 3.20mm
- Tip
- Header, Male Pins, Shrouded (2 Side)
- Option
- GENERAL PURPOSE
- Ul Flammability Code
- 94V-0
- Currentiec
- 17A
- Material Flammability Rating
- UL94 V-0
