Volume pricing
- 1+ pcs$2.96
- 10+ pcs$2.79
- 100+ pcs$2.64
- 500+ pcs$2.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge
- 12-26 AWG
- Flammability Rating
- UL94 V-2
- Nominal Gerilim
- 300V
- Terminal And Terminal Block Type
- MODULAR TERMINAL BLOCK
- Sıra Sayısı
- 1
- Akım
- 20A
- Housing Material
- Polyamide (PA), Nylon
- Number Of Decks
- 1
- Pitch
- 0.300 7.62mm
- Wire Termination
- Screw - Clamping Yoke, Tension Sleeve
- Radyasyon Dayanımı
- No
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Max
- 26 AWG
- Max Supply Voltage
- 300V
- Fabrika Tedarik Süresi
- 6 Weeks
- Özellikler
- Interlocking (Side)
- ECCN Kodu
- EAR99
- Mating Orientation
- Horizontal with Board
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -50°C~100°C
- Seri
- Omnimate LP
- Montaj
- Through Hole
- Kurşunsuz Kodu
- yes
- Wire Gauge Min
- 12 AWG
- Onay Kuruluşu
- CSA, UR
- Number Of Ways
- 2
- Contact Plating
- Tin
- Insulation Materials
- Nylon
- Number Of Levels
- 1
- Montaj Tipi
- Through Hole
- Uzunluk
- 15.87mm
- Number Of Positions Per Level
- 2
- Max Current Rating
- 10A
- Yayın Yılı
- 2011
- Orientation
- Straight
- HTS Kodu
- 8536.69.40.40
- Ambalaj
- Bulk
- Contact Material Plating
- Copper Alloy - Tin Plated
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 6mm
