Specifications
- Wire Gauge Or Range Awg
- 14-26 AWG
- Yükseklik
- 12.2mm
- Çalışma Sıcaklığı
- -50°C~100°C
- Pitch
- 0.200 5.08mm
- Number Of Levels
- 1
- Montaj
- Cable, Free Hanging
- Akım
- 10A
- Kurşunsuz Kodu
- yes
- Seri
- Omnimate BL
- Din Conformance
- NO
- Sıra Sayısı
- 1
- Tip
- Plug, Female Sockets
- Flammability Rating
- UL94 V-0
- Insulation Height
- 0.480 12.20mm
- Contact Mating Finish
- Tin
- Plug Wire Entry
- 180°
- Iec Conformance
- NO
- Wire Strip Length
- 13mm
- Ul Flammability Code
- 94V-0
- Gender
- Male
- Uzunluk
- 40.6mm
- Currentul
- 17A
- Mixed Contacts
- NO
- Housing Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Gerilim
- 300V
- Genişlik
- 31.8mm
- Orientation
- Straight
- Radyasyon Dayanımı
- No
- Renk
- Black
- Currentiec
- 27A
- RoHS Durumu
- RoHS Compliant
- Screw Size
- M2.5
- Terminal Stili
- Screw - TOP Clamp
- Voltageiec
- 400V
- Parça Durumu
- Active
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Option
- GENERAL PURPOSE
- Özellikler
- Retention Latches (Non-Wire Side)
- Material Flammability Rating
- UL94 V-0
- Number Of Contacts
- 8
