Specifications
- Number Of Ways
- 9
- Onay Kuruluşu
- CSA
- Flammability Rating
- UL94 V-2
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Genişlik
- 18.5mm
- Mating Orientation
- Vertical with Board
- Parça Durumu
- Active
- Contact Plating
- Tin
- Çalışma Sıcaklığı
- -50°C~100°C
- Contact Material Plating
- Brass - Tin Plated
- Max Supply Voltage
- 300V
- Number Of Decks
- 1
- Yayın Yılı
- 2008
- Screw Thread
- M2.5
- Özellikler
- Interlocking (Side)
- Wire Gauge Min
- 14 AWG
- Pozisyon Sayısı
- 9
- Housing Material
- Polyamide (PA), Nylon
- Pitch
- 0.200 5.08mm
- Hole Diameter
- 1.3 mm
- Uzunluk
- 50.02mm
- Wire Cross Section
- 2.5 mm2
- Stripping Length
- 10mm
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Radyasyon Dayanımı
- No
- Seri
- Omnimate TOP1.5GS
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım Değeri
- 10A
- Insulation Materials
- Nylon
- Ambalaj
- Bulk
- Wire Termination
- Screw - TOP Clamp
- Contact Materials
- CuZn
- Wire Gauge Max
- 26 AWG
- Nominal Gerilim
- 300V
- Renk
- Orange
- Fabrika Tedarik Süresi
- 12 Weeks
- Terminal
- Solder
- Montaj
- Through Hole
- Sıra Sayısı
- 1
