Specifications
- Depth
- 20mm
- Ambalaj
- Bulk
- Wire Gauge Min
- 12 AWG
- Number Of Contacts
- 2
- Parça Durumu
- Active
- Number Of Levels
- 1
- Yayın Yılı
- 2008
- Max Supply Voltage
- 300V
- Housing Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Terminal
- Screw
- Uzunluk
- 12.16mm
- Kurşunsuz Kodu
- yes
- Plug Wire Entry
- 180°
- Montaj Tipi
- Free Hanging (In-Line)
- Iec Conformance
- NO
- Material Flammability Rating
- UL94 V-0
- Montaj
- Cable, Free Hanging
- Akım
- 10A
- Wire Strip Length
- 7mm
- Pitch
- 0.200 5.08mm
- Filter Feature
- NO
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Wire Gauge Or Range Awg
- 12-26 AWG
- Currentiec
- 17.5A
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Stili
- Screw - Clamping Yoke (Tension Sleeve)
- Genişlik
- 20mm
- Insulation Height
- 0.598 15.19mm
- Option
- GENERAL PURPOSE
- Voltageiec
- 400V
- Renk
- Orange
- Mixed Contacts
- NO
- Flammability Rating
- UL94 V-0
- Kurşunsuz
- Lead Free
- Screw Size
- M2.5
- Mil Conformance
- NO
- Contact Materials
- Copper Alloy
- Max Current Rating
- 10A
- Tip
- Plug, Female Sockets
