Volume pricing
- 1+ pcs$9.56
- 10+ pcs$9.02
- 100+ pcs$8.51
- 500+ pcs$8.03
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Currentiec
- 13.4A
- Header Orientation
- Vertical
- Tip
- Header, Male Pins, Shrouded (4 Side)
- Positions Per Level
- 8
- Yayın Yılı
- 2012
- Flammability Rating
- UL94 V-0
- Özellikler
- Mating Flange, Solder Retention
- Montaj
- Through Hole
- Pitch
- 0.138 3.50mm
- RoHS Durumu
- RoHS Compliant
- Ingress Protection
- IP20
- Contact Tail Length
- 0.138 3.50mm
- Ambalaj
- Bulk
- Akım Değeri
- 10A
- Housing Material
- Liquid Crystal Polymer (LCP), Glass Filled
- Voltageiec
- 200V
- Montaj Tipi
- Through Hole
- Contact Materials
- Copper Alloy
- Seri
- Omnimate S2C
- Number Of Decks
- 1
- Pozisyon Sayısı
- 16
- Additional Feature
- STANDARD: UL 94V-0, GLASS FILLED LCP
- Renk
- Black
- Terminal Stili
- Solder
- Hole Diameter
- 1.3 mm
- Contact Mating Finish
- Tin
- Gerilim
- 150V
- Fabrika Tedarik Süresi
- 12 Weeks
- Çalışma Sıcaklığı
- -50°C~120°C
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Fastening Method
- CONNECTOR
- Sıra Sayısı
- 1
- Number Of Ways
- 16
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Height
- 0.559 14.20mm
- Nominal Gerilim
- 150V
- Akım
- 10A
- Safety Approval
- CSA; CUL; EAC; IEC; UL
