Specifications
- Fabrika Tedarik Süresi
- 10 Weeks
- Genişlik
- 5.16mm
- Yükseklik
- 21.3mm
- Montaj Tipi
- Through Hole
- Diode Configuration
- 1 Pair Common Cathode
- Number Of Phases
- 1
- Max Surge Current
- 350A
- Parça Durumu
- Active
- Forward Voltage
- 640mV
- Pin Sayısı
- 2
- Kurşunsuz Kodu
- yes
- Terminal Pozisyonu
- SINGLE
- Uzunluk
- 16.4mm
- Applications
- EFFICIENCY
- Diode Type
- Schottky
- Number Of Elements
- 2
- Max Repetitive Reverse Voltage Vrrm
- 60V
- Peak Nonrepetitive Surge Current
- 350A
- Terminal Sayısı
- 3
- Tepe Reflow Sıcaklığı (°C)
- 260
- Diode Element Material
- SILICON
- Yayın Yılı
- 2016
- Peak Reverse Current
- 600μA
- Radyasyon Dayanımı
- No
- Maks. Çalışma Sıcaklığı
- 150°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- TO-3P-3, SC-65-3
- JESD-609 Kodu
- e3
- Forward Current
- 60A
- Ambalaj
- Tube
- Pin Sayısı
- 3
- RoHS Durumu
- ROHS3 Compliant
- Additional Feature
- FREE WHEELING DIODE, LOW POWER LOSS
- Element Configuration
- Common Cathode
- Current Reverse Leakage Vr
- 600μA @ 60V
- Terminal Kaplaması
- MATTE TIN
- Average Rectified Current
- 30A
- Max Reverse Voltage Dc
- 60V
- Jedec95 Code
- TO-247AD
- Max Reverse Leakage Current
- 600μA
