Specifications
- Dc Resistance Dcr
- 127mOhm Max
- Çalışma Sıcaklığı
- -55°C~180°C
- ECCN Kodu
- EAR99
- Reach Svhc
- Unknown
- Case Code Imperial
- 2525
- Terminal Sayısı
- 2
- Packing Method
- TR, 13 Inch
- Tolerans
- ±20%
- Shielding
- YES
- Terminal Kaplaması
- Tin (Sn) - with Nickel (Ni) barrier
- JESD-609 Kodu
- e3
- Tip
- Molded
- Inductance Tolerance
- 20%
- Frequencyselfresonant
- 11MHz
- Boyut / Ölçü
- 0.270Lx0.255W 6.86mmx6.47mm
- Terminal Placement
- DUAL ENDED
- Ambalaj
- Tape & Reel (TR)
- Shapesize Description
- RECTANGULAR PACKAGE
- Depth
- 6.47mm
- Terminal Shape
- WRAPAROUND
- Terminal
- SMD/SMT
- Parça Durumu
- Active
- Akım Değeri
- 2.9A
- Montaj
- Surface Mount
- Endüktans
- 15μH
- Maks. Oturma Yüksekliği
- 0.118 3.00mm
- Test Frequency
- 100kHz
- Direnç
- 118mOhm
- Yayın Yılı
- 2006
- Seri
- IHLP-2525CZ-8A
- Casesize Code
- 2726
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Surface Mount
- Kılıf / Paket
- Nonstandard
- Current Saturation
- 2.8A
- Construction
- Rectangular
- Inductor Application
- HIGH CURRENT INDUCTOR
- Rms Current Irms
- 2.9A
- Case Code Metric
- 6363
- Fabrika Tedarik Süresi
- 22 Weeks
