Specifications
- Secondary Windings
- Single
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- HTS Kodu
- 8504.31.40.65
- Tip
- Laminated Core
- Voltage Primary
- 115V 230V
- Montaj Tipi
- Chassis Mount
- Fabrika Tedarik Süresi
- 17 Weeks
- Yayın Yılı
- 2014
- Terminal
- Quick Connect
- Output Voltage1
- 36V
- Montaj
- Chassis Mount, Flanges, Panel
- Maks. Oturma Yüksekliği
- 65.07mm
- Power Rating
- 100W
- ECCN Kodu
- EAR99
- Power Max
- 100VA
- Kurşunsuz Kodu
- yes
- Voltage Isolation
- 2500VAC
- Applications
- POWER
- Boyut / Ölçü
- 102.39mm Lx57.15mm W
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Seri
- Quick Pack
- RoHS Durumu
- ROHS3 Compliant
- Va Rating
- 100 VA
- Max Power Dissipation
- 100W
- Nem Hassasiyeti (MSL)
- Not Applicable
- Voltage Secondary Full Load
- 36V
- Primary Windings
- Dual
- Center Tap
- Yes
- Output Current
- 2.8A
- Weight
- 2.8lbs 1.3kg
- Onay Kuruluşu
- UL
- Pin Sayısı
- 7
- Yükseklik
- 65.0748mm
