Specifications
- Voltage Secondary Full Load
- 12.6V
- Pin Sayısı
- 5
- Terminal Stili
- Wire Leads
- Yayın Yılı
- 2005
- Boyut / Ölçü
- 93.65mm Lx50.80mm W
- Element Configuration
- Single
- Voltage Primary
- 115V
- RoHS Durumu
- ROHS3 Compliant
- Tip
- Laminated Core
- Voltage Isolation
- 1500Vrms
- Center Tap
- Yes
- Terminal
- Wire Leads
- Max Power Dissipation
- 31.5W
- Uzunluk
- 93.65mm
- Montaj
- Chassis Mount, Flanges, Panel
- Nominal Input Voltage
- 115V
- Primary Windings
- Single
- Weight
- 1.6lbs 725.7g
- Power Rating
- 31.5W
- Max Output Current
- 2.5A
- Onay Kuruluşu
- UL
- Maks. Oturma Yüksekliği
- 57.94mm
- Seri
- Single Secondary
- Nem Hassasiyeti (MSL)
- Not Applicable
- Output Voltage
- 12.6V
- Secondary Windings
- Single
- Secondary Current
- 2.5A
- Reach Svhc
- No SVHC
- Akım Değeri
- 2.5A
- Montaj Tipi
- Chassis Mount
- Fabrika Tedarik Süresi
- 17 Weeks
- Power Max
- 31.5VA
- Output Current
- 2.5A
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Genişlik
- 50.8mm
