Volume pricing
- 1+ pcs$17.62
- 10+ pcs$16.63
- 100+ pcs$15.68
- 500+ pcs$14.80
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Power Dissipation
- 14W
- Uzunluk
- 82.55mm
- Montaj
- Chassis Mount, Flanges
- Tip
- Laminated Core
- Voltage Isolation
- 1500Vrms
- Center Tap
- Yes
- Terminal
- Wire Leads
- Pin Sayısı
- 5
- Terminal Stili
- Wire Leads
- Yayın Yılı
- 2014
- Boyut / Ölçü
- 82.55mm Lx44.45mm W
- Element Configuration
- Single
- RoHS Durumu
- ROHS3 Compliant
- Voltage Primary
- 115V
- Voltage Secondary Full Load
- 14V
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Genişlik
- 44.45mm
- Secondary Current
- 1A
- Montaj Tipi
- Chassis Mount
- Power Max
- 14VA
- Fabrika Tedarik Süresi
- 17 Weeks
- Max Output Current
- 1A
- Maks. Oturma Yüksekliği
- 49.20mm
- Seri
- Single Secondary
- Nem Hassasiyeti (MSL)
- Not Applicable
- Secondary Windings
- Single
- Primary Windings
- Single
- Weight
- 1.2lbs 544.3g
- Power Rating
- 1W
