Volume pricing
- 1+ pcs$8.00
- 10+ pcs$7.55
- 100+ pcs$7.12
- 500+ pcs$6.72
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Stili
- PC Pin
- Va Rating
- 12 VA
- Seri
- Split Pack™, Class 2/3, F
- Max Output Current
- 1A
- Fabrika Tedarik Süresi
- 17 Weeks
- Pin Sayısı
- 6
- Input Voltagenom
- 115V
- HTS Kodu
- 8504.31.40.35
- Montaj
- PCB, Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Weight
- 0.7lb 317.51g
- Voltage Isolation
- 2500Vrms
- Kurşunsuz
- Lead Free
- Primary Windings
- Single
- Output Voltage2
- 12V
- Terminal
- PC Pin
- Applications
- POWER
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kurşunsuz Kodu
- yes
- Center Tap
- No
- Yükseklik
- 36.4998mm
- Power Rating
- 12W
- Max Power Dissipation
- 12W
- Akım Değeri
- 500mA
- Voltage Secondary Full Load
- Parallel 12V Series 24V
- Boyut / Ölçü
- 47.63mm Lx39.67mm W
- Yayın Yılı
- 2014
- Montaj Tipi
- Through Hole
- Voltage Primary
- 115V
- Maks. Oturma Yüksekliği
- 36.50mm
- Secondary Windings
- Dual
- Power Max
- 12VA
- Parça Durumu
- Active
- Output Voltage1
- 12V
- Tip
- Laminated Core
- Onay Kuruluşu
- UL
- ECCN Kodu
- EAR99
