Volume pricing
- 1+ pcs$5.24
- 10+ pcs$4.94
- 100+ pcs$4.66
- 500+ pcs$4.40
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Tip
- Laminated Core
- Voltage Secondary Full Load
- Parallel 6.3V Series 12.6V
- Kurşunsuz Kodu
- yes
- Terminal
- PC Pin
- Voltage Primary
- 115V
- Voltage Isolation
- 2500Vrms
- Va Rating
- 2.5 VA
- Kurşunsuz
- Lead Free
- Max Power Dissipation
- 2.5W
- Onay Kuruluşu
- UL
- Center Tap
- No
- Weight
- 0.25lb 113.4g
- Boyut / Ölçü
- 34.93mm Lx28.58mm W
- Uzunluk
- 34.92mm
- Yayın Yılı
- 2008
- Terminal Stili
- PC Pin
- Pin Sayısı
- 6
- Applications
- POWER
- Maks. Oturma Yüksekliği
- 30.15mm
- ECCN Kodu
- EAR99
- Primary Windings
- Single
- Fabrika Tedarik Süresi
- 17 Weeks
- Seri
- Split Pack™, Class 2/3, F
- Akım Değeri
- 200mA
- Power Max
- 2.5VA
- Max Output Current
- 200mA
- Nem Hassasiyeti (MSL)
- Not Applicable
- RoHS Durumu
- ROHS3 Compliant
- Min. Çalışma Sıcaklığı
- 0°C
- Montaj Tipi
- Through Hole
- Secondary Windings
- Dual
- HTS Kodu
- 8504.31.40.35
- Input Voltagenom
- 115V
- Maks. Çalışma Sıcaklığı
- 25°C
- Montaj
- PCB, Through Hole
- Physical Dimension
- L34.92XB28.57XH30.15 (mm)
- Power Rating
- 2.5W
- Genişlik
- 28.57mm
- Parça Durumu
- Active
