Specifications
- Seri
- Split Pack™, Class 2/3, F
- Primary Windings
- Single
- Fabrika Tedarik Süresi
- 17 Weeks
- Power Max
- 12VA
- HTS Kodu
- 8504.31.40.35
- Secondary Windings
- Dual
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 36.5mm
- RoHS Durumu
- ROHS3 Compliant
- Max Output Current
- 1A
- Parça Durumu
- Active
- Power Rating
- 12W
- Montaj
- PCB, Through Hole
- Input Voltagenom
- 115V
- Voltage Primary
- 115V
- Kurşunsuz Kodu
- yes
- Terminal
- PC Pin
- Voltage Secondary Full Load
- Parallel 6.3V Series 12.6V
- Tip
- Laminated Core
- Onay Kuruluşu
- UL
- Center Tap
- No
- Weight
- 0.7lb 317.51g
- Kurşunsuz
- Lead Free
- Max Power Dissipation
- 12W
- Voltage Isolation
- 2500Vrms
- Va Rating
- 12 VA
- Pin Sayısı
- 6
- Terminal Stili
- PC Pin
- Yayın Yılı
- 2008
- Boyut / Ölçü
- 47.63mm Lx39.67mm W
- ECCN Kodu
- EAR99
- Maks. Oturma Yüksekliği
- 36.50mm
- Applications
- POWER
