Volume pricing
- 1+ pcs$9.07
- 10+ pcs$8.55
- 100+ pcs$8.07
- 500+ pcs$7.61
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Min. Çalışma Sıcaklığı
- 0°C
- Secondary Windings
- Single
- Fabrika Tedarik Süresi
- 17 Weeks
- Primary Windings
- Single
- Maks. Çalışma Sıcaklığı
- 130°C
- Seri
- Single Secondary
- Tip
- Laminated Core
- Pin Sayısı
- 5
- Max Power Dissipation
- 2.04W
- Terminal
- Wire Leads
- Reach Svhc
- No SVHC
- Terminal Stili
- Wire Leads
- Boyut / Ölçü
- 52.37mm Lx34.93mm W
- Parça Durumu
- Active
- Power Rating
- 2.04W
- Montaj Tipi
- Chassis Mount
- Power Max
- 2.04VA
- Kurşunsuz
- Lead Free
- Akım Değeri
- 85mA
- Voltage Isolation
- 1500Vrms
- Voltage Primary
- 115V
- Montaj
- Chassis Mount, Flanges
- Maks. Oturma Yüksekliği
- 30.15mm
- Yayın Yılı
- 2006
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 52.37mm
- Genişlik
- 34.93mm
- Element Configuration
- Single
- Output Current
- 85mA
- Weight
- 0.3lb 136.08g
- Voltage Secondary Full Load
- 24V
- Max Output Current
- 85mA
- Output Voltage
- 24V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Nominal Input Voltage
- 115V
- Center Tap
- Yes
