Specifications
- Supply Voltagemax Vsup
- 30V
- Voltage Load
- 10V~27V
- Pin Sayısı
- 22
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 16mm
- Supply Voltagemin Vsup
- 10V
- Motor Type Ac Dc
- Brushed DC
- Output Configuration
- Half Bridge (2)
- Ambalaj
- Tape & Reel (TR)
- Kılıf / Paket
- 20-BSOP (0.346, 8.80mm Width) + 2 Heat Tabs
- Maks. Oturma Yüksekliği
- 2.7mm
- Fabrika Tedarik Süresi
- 2 Weeks
- Radyasyon Dayanımı
- No
- Interface
- PWM, Serial
- Terminal Adımı
- 1mm
- Besleme Gerilimi
- 10V~27V
- Montaj
- Surface Mount
- Terminal Pozisyonu
- DUAL
- Yayın Yılı
- 2010
- Terminal Formu
- GULL WING
- Terminal Sayısı
- 20
- Besleme Gerilimi
- 24V
- Jesd30 Code
- R-PDSO-G20
- Analog Ic Other Type
- BRUSH DC MOTOR CONTROLLER
- Applications
- General Purpose
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Function
- Driver - Fully Integrated, Control and Power Stage
- Montaj Tipi
- Surface Mount
- Genişlik
- 8.8mm
- Çalışma Sıcaklığı
- -20°C~85°C TA
- Temel Parça No
- TB6549
- Logic Function
- AND
