Volume pricing
- 1+ pcs$7.82
- 10+ pcs$7.38
- 100+ pcs$6.96
- 500+ pcs$6.57
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Adımı
- 0.5mm
- Max Supply Current
- 800μA
- Pin Sayısı
- 9
- Montaj Tipi
- Surface Mount
- Montaj
- Surface Mount
- Lifecycle Status
- ACTIVE (Last Updated: 5 days ago)
- Temel Parça No
- UCC27200
- Max Output Current
- 3A
- Output Current Flow Direction
- SOURCE SINK
- Current Peak Output Source Sink
- 3A 3A
- Number Of Outputs
- 2
- Çalışma Sıcaklığı
- -40°C~140°C TJ
- JESD-609 Kodu
- e4
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Kılıf / Paket
- 10-VFDFN Exposed Pad, 9 Leads
- Qualification Status
- Not Qualified
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- 2 (1 Year)
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Parça Durumu
- Active
- Ambalaj
- Tape & Reel (TR)
- Driver Configuration
- Half-Bridge
- Output Peak Current Limitnom
- 3A
- Genişlik
- 3mm
- RoHS Durumu
- ROHS3 Compliant
- Giriş Tipi
- Non-Inverting
- Kurşunsuz
- Lead Free
- Turn On Delay Time
- 7 ns
- Logic Voltagevil Vih
- 3V 8V
- Tepe Reflow Sıcaklığı (°C)
- 260
- Uzunluk
- 3mm
- Yükseklik
- 1mm
- Gate Type
- N-Channel MOSFET
- Terminal Formu
- NO LEAD
- Channel Type
- Independent
- Rise Fall Time Typ
- 8ns 7ns
- High Side Voltage Max Bootstrap
- 120V
- Max Power Dissipation
- 2.86W
- Fonksiyon Sayısı
- 1
- Terminal Sayısı
- 9
