Specifications
- Frekans
- 450kHz
- Kılıf / Paket
- 24-DIP (0.600, 15.24mm)
- Synchronous Rectifier
- Yes
- Input Voltagenom
- 15V
- Additional Feature
- CAN ALSO WORK IN CURRENT MODE
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj
- Through Hole
- Frequency Switching
- 220kHz
- Function
- Step-Down, Step-Up/Step-Down
- Rise Time
- 40ns
- RoHS Durumu
- ROHS3 Compliant
- Terminal Pozisyonu
- DUAL
- Number Of Outputs
- 3
- Nominal Input Voltage
- 15V
- Kurşunsuz Kodu
- yes
- Temel Parça No
- UC3827
- Çıkış Tipi
- Transistor Driver
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Control Mode
- VOLTAGE-MODE
- Control Features
- Frequency Control, Ramp, Soft Start
- Qualification Status
- Not Qualified
- Ambalaj
- Tube
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole
- Control Technique
- PULSE WIDTH MODULATION
- Output Current
- 100mA
- Duty Cycle Max
- 91%
- Output Voltage
- 2.5V
- Voltage Supply Vccvdd
- 7.6V~20V
- Kurşunsuz
- Lead Free
- Analog Ic Other Type
- SWITCHING CONTROLLER
- Output Configuration
- Positive
- Topology
- Buck, Full-Bridge, Push-Pull
- Çalışma Sıcaklığı
- 0°C~70°C TA
- Max Duty Cycle
- 50 %
- ECCN Kodu
- EAR99
- Output Phases
- 1
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Terminal Sayısı
- 24
- Fall Time Typ
- 30 ns
