Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Tube
- Control Features
- Frequency Control, Ramp, Soft Start
- Control Mode
- VOLTAGE-MODE
- Kurşunsuz
- Lead Free
- Output Voltage
- 2.5V
- Voltage Supply Vccvdd
- 7.6V~20V
- Duty Cycle Max
- 91%
- Montaj Tipi
- Through Hole
- Control Technique
- PULSE WIDTH MODULATION
- Output Current
- 100mA
- Çalışma Sıcaklığı
- 0°C~70°C TA
- Topology
- Buck, Full-Bridge, Push-Pull
- Analog Ic Other Type
- SWITCHING CONTROLLER
- Output Configuration
- Positive
- Radyasyon Dayanımı
- No
- Parça Durumu
- Obsolete
- Pin Sayısı
- 24
- Genişlik
- 13.71mm
- Terminal Adımı
- 2.54mm
- JESD-609 Kodu
- e4
- Output Phases
- 1
- Terminal Sayısı
- 24
- Fall Time Typ
- 30 ns
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Max Duty Cycle
- 95 %
- ECCN Kodu
- EAR99
- Additional Feature
- CAN ALSO WORK IN CURRENT MODE
- Synchronous Rectifier
- Yes
- Input Voltagenom
- 15V
- Frekans
- 450kHz
- Kılıf / Paket
- 24-DIP (0.600, 15.24mm)
- Function
- Step-Down, Step-Up/Step-Down
- Montaj
- Through Hole
- Frequency Switching
- 220kHz
- Nominal Input Voltage
- 15V
- Rise Time
- 40ns
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 31.75mm
- Number Of Outputs
- 3
