Specifications
- Thickness
- 500μm
- Yüzey Montaj
- YES
- Pin Sayısı
- 6
- Radyasyon Dayanımı
- No
- Clamping Voltage
- 105.5V
- Test Current
- 10mA
- Direction
- Unidirectional
- Tip
- Steering (Rail to Rail)
- Number Of Elements
- 1
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Terminal Pozisyonu
- DUAL
- Terminal
- SMD/SMT
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- 6-UFDFN
- Ambalaj
- Tape & Reel (TR)
- Configuration
- SINGLE
- Diode Element Material
- SILICON
- Peak Pulse Power
- 90W
- Montaj Tipi
- Surface Mount
- JESD-609 Kodu
- e4
- Reach Svhc
- No SVHC
- Number Of Channels
- 3
- Working Voltage
- 5.5V
- Tepe Reflow Sıcaklığı (°C)
- 260
- Breakdown Voltage V
- 11V
- Voltage Reverse Standoff Typ
- 5.5V Max
- Max Reverse Leakage Current
- 1nA
- Depth
- 1mm
- Power Line Protection
- Yes
- Pin Sayısı
- 6
- Temel Parça No
- TPD3E001
- Interface
- USB
- Kurşunsuz Kodu
- yes
- Leakage Current
- 1nA
- Operating Supply Voltage
- 5.5V
- Çalışma Sıcaklığı
- -40°C~85°C TA
- Terminal Sayısı
- 6
- Parça Durumu
- Active
- Reverse Standoff Voltage
- 5.5V
- Fabrika Tedarik Süresi
- 6 Weeks
