Specifications
- Direction
- Unidirectional
- Tip
- Steering (Rail to Rail)
- Kurşunsuz Kodu
- yes
- Clamping Voltage
- 12.4V
- Çalışma Sıcaklığı
- -40°C~125°C TA
- Terminal Sayısı
- 3
- Number Of Elements
- 1
- Voltage Reverse Standoff Typ
- 5.5V Max
- Tepe Reflow Sıcaklığı (°C)
- 260
- Contact Plating
- Gold
- Thickness
- 1mm
- Terminal Formu
- GULL WING
- Temel Parça No
- TPD2E2U06
- Pin Sayısı
- 3
- Voltage Clamping Max Ipp
- 12.4V Typ
- Interface
- Ethernet, LVDS, USB
- Power Line Protection
- Yes
- Pin Sayısı
- 3
- Seri
- Automotive, AEC-Q101
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Voltage Breakdown Min
- 6.5V
- Montaj Tipi
- Surface Mount
- Montaj
- Surface Mount
- JESD-609 Kodu
- e4
- Applications
- Automotive, Ethernet
- Kurşunsuz
- Lead Free
- Uzunluk
- 2.92mm
- Yükseklik
- 1.22mm
- Number Of Channels
- 2
- Working Voltage
- 5.5V
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- 2 (1 Year)
- Peak Pulse Current
- 5.5A
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Parça Durumu
- Active
- Reverse Standoff Voltage
- 5.5V
- Fabrika Tedarik Süresi
- 6 Weeks
- Current Peak Pulse101000s
- 5.5A 8/20μs
- Ambalaj
- Tape & Reel (TR)
- Kapasitans
- 1.9pF
