Specifications
- Voltage Reverse Standoff Typ
- 3.6V Max
- Yüzey Montaj
- YES
- Breakdown Voltage V
- 6.4V
- Thickness
- 370μm
- Voltage Clamping Max Ipp
- 15V
- Polarity
- BIDIRECTIONAL
- Power Peak Pulse
- 27W
- Interface
- HDMI, USB
- Temel Parça No
- TPD1E01B04
- Power Line Protection
- No
- Pin Sayısı
- 2
- Tip
- Zener
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 2
- Terminal Pozisyonu
- DUAL
- Çalışma Sıcaklığı
- -40°C~125°C TA
- Operating Supply Voltage
- 3.6V
- Number Of Elements
- 1
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 12 Weeks
- Current Peak Pulse101000s
- 2.5A 8/20μs
- Bidirectional Channels
- 1
- Parça Durumu
- Active
- Capacitance Frequency
- 0.2pF @ 1MHz
- Configuration
- SINGLE
- Ambalaj
- Tape & Reel (TR)
- Genişlik
- 1mm
- Diode Element Material
- SILICON
- Kılıf / Paket
- 0402 (1006 Metric)
- JESD-609 Kodu
- e4
- Montaj Tipi
- Surface Mount
- Applications
- General Purpose
- Voltage Breakdown Min
- 6.4V Typ
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Uzunluk
- 600μm
- Yükseklik
- 450μm
